Migration from Cisco 1000v to VMware Virtual Distributed Switch (Part 2)

home_network3

This is part 2 of a series. Click here to see Part 1. I apologise for taking so long to get Part 2 posted. Sometimes I just don’t have the time or effort I would like to have with the blog.

000193_2015-10-29 10_06

This portion of the guide focuses on the second half of the VSS to VDS migrations. We needed to move the VMs to a VSS so that you can migrate both VMs and hosts to the new vCenter cleanly. Then we will be moving the VMs back to a VDS from their VSS configuration.

Keep in mind this migration is being done LIVE with production virtual machines running on the hosts. Obviously, this must be executed carefully or you will have a lot of explaining to do. Do not make these changes without understanding the full impact to your environment. Continue reading…

WHMCS – Is the promo applied or not?

WHMCS62CloudSliderWithZoom

WHMCS is one of the most popular billing systems for web hosting companies. Despite this fact there are many small caveats and grudges you will find with the WHMCS platform.

For example, when a customer is passed to an order page using a link with a promotional code or with an existing promo code applied the order summary does not show the discounted total. The discounted total is only shown on the checkout page. How stupid? This simple mistake by WHMCS’s developers can not only increase customer cart abandonment rates but also confuse the customer whether the discount is applied or not. Put simply, it grinds my gears as well. Continue reading…

Virtual Firewall and Networking – Planning Guide

This is a planning guide on how to create a robust, redundant, virtual network for your home-lab environment including a virtual firewall. This requires a lot of existing hardware and expertise. This is not recommended the faint of heart and will challenge you. Using a physical firewall is the easy choice.

Cisco_Nexus_3000_Series_1

I have structured this guide around how I have my own network configured for the vSkilled home lab. I have been running in this configuration for literally years without incident. You should first weigh the pros and cons for your own environment and then decide if this design is the right choice for YOU. Just because it works for me, does not mean it will work for you. There are many mixed opinions between running your firewall physically or virtually. Neither is right or wrong. That really depends entirely on your skill level and the equipment you have available. You should decide on a network topology which you are most comfortable troubleshooting and fixing when it breaks.

Continue reading…

Home Labs: Remote Access and Security

I am sure that most who have a lab environment in their home also have a way of remotely accessing it – either from at work, with friends or family, vacation, etc. The problem with any remote access into a secure network is that you are quite literally punching a hole into your network from a security sense to allow that to happen.

People seem to have a lot of mixed feelings about allowing Remote Desktop Protocol (RDP) into their home network from the Internet. As a general blanket statement without context, I would completely agree. Opening RDP (port 3389) directly to the Internet without any other security measures in place is asking for trouble. The default RDP port will be constantly brute forced, port scanned, exploited, and the list goes on.

With that said there are steps you can take to have secure remote access to your home network using RDP, SSH, etc.

Many of these concerns can be minimized or eliminated using some of these best practices:

  1. Restrict access using firewalls
  2. Change the listening port for Remote Desktop Protocol
  3. Use two-factor authentication
  4. Use strong passwords
  5. Set an account lockout policy

1 – Restrict access using firewalls

Having a proper firewall and firewall rules in place is critical for protecting your network from outside threats. And I’m not talking about the built-in firewall on your ISP’s provided/rented crappy router/modem – these are a very poor excuse and implementation of a “firewall”- not to mention your ISP normally hard codes back-doors and default logins. I’m talking about a real firewall either physical or virtual, for example; Cisco ASA, Cisco Meraki, Untangle, PF Sense, Sophos UTM/XGUbiquiti, etc. Any of these will give you the tools required to properly firewall your home network. All of these firewalls will require a ‘geek’ to properly setup – keep in mind this article is targeted to home lab hobbyists.

basic_networkTo the right is a good example of a very basic home network with a firewall. Anything before the firewall we treat as untrusted. The firewall is literally the barrier between your network and the big, bad, Internet. There you will define your firewall rules to allow remote access and other functionality (or lack-thereof).

Personally, I use Sophos UTM (see my homelab) with a DNAT (Destination Network Address Translation) rule to redirect the external facing remote access port to a specific server and port on my internal network. This allows me to create a matching condition (For traffic from, Using service/port, Going to) to apply an action (Change the destination to, And the service to) to define what happens when something wants to connect to my network. Using that logic I can (and do) restrict the IP blocks allowed to connect to my remote access port, what times of day, etc.

This allows me to both A; define a custom externally facing port without having to change the port on the server internally, and B; create firewall rules to restrict access even further from specific traffic sources, destinations and services.

The real-world implementation of this will vary based on your choice of firewall, your skills and personal preferences.

2 – Change the listening port for Remote Desktop Protocol

Changing the listening port of RDP is a quick and easy method of implementing security through obscurity. Doing so will help to hide your RDP port from threats who scan networks looking for computers listening on the default Remote Desktop port (TCP 3389).

There are a number of ways to accomplish this. 1 – port redirection on your firewall/router, 2 – modifying the registry keys of the Windows computer locally, or 3 – using a Windows TS Gateway. Choose the method that works best for you.

3 – Use two-factor authentication

Using 2FA (two-factor authentication) is a no brainier these days. Two-factor authentication provides a second layer of security to any type of login, requiring extra information or a physical device to log in, in addition to your password. This protects user logins from remote attacks that may exploit stolen credentials.DuoScreen_740
I use Duo Security Personal edition on my remote RDP access to my home environment. I have configured Duo to only prompt 2FA if the source IP is external. That way I don’t need to use 2FA for local RDP sessions from within my LAN – which would just be annoying. Any time I want to login I just connect, enter my credentials, answer the 2FA prompt on my phone, and I’m in. The Duo Dashboard also has a wide range options, logging, and device fingerprinting. Duo works on a huge number of operating systems and platforms so you can integrate it into, almost, literally any part of your network as you deem fit.

If you are not already using 2FA in your network, start using it! It’s free and extremely easy to setup.

4 – Use strong passwords

While this one may seem like common sense, you would be surprised. A strong password should be at least 8 characters long using a combination of upper and lower case characters – including a mix of both numbers and symbols. Setting an insecure password on anything, let alone a remote entry point to your network could spell disaster.

One of the best ways to ensure that you use unique and strong passwords for systems and websites is to use a password manager. I personally use and recommend Dashlane.

5 – Set an account lockout policy

Brute force attacks are common problem for external facing ports and services. Remember that two-factor authentication only comes into effect once the password is correctly entered and will not prevent a brute force attack. Setting your computer to lock an account for a period of time after a number of incorrect guesses will help prevent attackers from using automated password guessing tools to break into your account.

  • Go to Start–> Programs –>Administrative Tools–> Local Security Policy
  • Under Account Policies –>Account Lockout Policies, set values for all three options.
    • 3 invalid attempts with 3 minute lockout durations are reasonable choices.

Conclusion

Hopefully these tips can help you to increase the security of your home network and remote access methods. If you know what you are doing and if done correctly you can have secure remote entry into your home network. This is not meant to be a be-all-end-all guide as there is no one size fits all for network security. This guide doesn’t even begin to dive into the more complex aspects of network security such as advanced threat protection, intrusion prevention, spoof & protocol protection, and so on.

Have more home lab security tips to share? Post them in the comments below!

Worried about Windows 10 privacy issues? Group/Local policy to the rescue!

win10privacy

I hear and see all over the Internet that people have privacy concerns about Windows 10 and for good reason. For any security concious person, like myself, they’re probably not very happy about many of the decisions that were made for Windows 10. Microsoft seems to be very tight lipped about their updates and what information is actually shared in their “learning” and “telemetry” information that is sent back to the Microsoft mother ship. There are also many other features included in Windows 10 that are, or could be seen as, a privacy concern; such as the advertising ID, WiFi Sense, Cortana, and the list goes on…

One of the biggest worries, though, is Microsoft’s policy on disclosing or sharing your personal information. The following is an excerpt from the privacy policy:

“We will access, disclose and preserve personal data, including your content (such as the content of your emails, other private communications or files in private folders), when we have a good faith belief that doing so is necessary to protect our customers or enforce the terms governing the use of the services.”

I’m sure many from the IT community are aware of Microsoft’s direct involvement with Government spying programs – so make no mistake, you are being watched. Continue reading…

Enable SNMP on ESXi 5.5

000174_2015-07-30 11_27

This is a quick guide on how to configure ESXi 5.5 hosts for SNMP monitoring. I use Observium to monitor and collect information about devices on my home network that support SNMP. This allows me to have an in-depth look at devices on my network as well as see metrics that go far into the past.

First we need to SSH to the ESXi host you would like to enable SNMP on. To do that we first need to make sure that SSH is enabled on the host.

Ensure that SSH is enabled on the ESXi Host:

  1. Go to the configuration tab, then select Security Profile
  2. Select Properties with Services, then select SSH Server
  3. Click the Start button once to start the service for now

000175_2015-07-30 11_33

Using an SSH client, such as Putty, connect to your ESXi host. Then run the following commands:

esxcli system snmp set -c public
esxcli system snmp set -l warning
esxcli system snmp set -e yes

That’s it! You can change the “public” string to whatever your preferred community name is. Now you can disable SSH on the host if you prefer. Then add the host into your SNMP monitoring tool. Wait 5-10 minutes for discovery and your finished.

000173_2015-07-30 11_26
